Product Overview

The Poline PN16 Dual Plate Check Valve with SS304 Disc – Wafer Type is designed for automatic backflow prevention in water, HVAC, fire fighting, utility, and industrial pipeline systems. Manufactured as per API 594, this compact wafer type valve saves installation space while delivering dependable check valve performance.

The valve uses spring assisted dual plates for rapid closing action, helping reduce reverse flow and minimizing water hammer effects. Its cylindrical body distributes stresses uniformly, while the streamlined internal flow path offers low pressure drop and better operating efficiency.

The SS304 stainless steel disc provides excellent corrosion resistance, longer service life, and suitability for water and moderately corrosive service conditions.

Key Features

• Designed as per API 594
• Tested as per API 598
• Wafer type compact body for space-saving installation
• Dual plate spring assisted closing
• Helps minimize water hammer
• Low pressure drop design
• SS304 stainless steel disc for corrosion resistance
• Lightweight body reduces support requirements
• Compatible with ANSI / ASME Class 125 / 150 flanges
• Reliable reverse flow protection

Technical Specifications

Applications

The Poline Dual Plate Check Valve is widely used in:

• Water supply systems
• HVAC systems
• Fire fighting lines
• Pump discharge lines
• Utility pipelines
• Industrial process lines
• Cooling water systems
• Commercial buildings

Why Choose Poline Check Valves?

Poline Valves manufactures dependable backflow prevention valves engineered for compact installation, efficient flow, and long service life. Our SS304 disc models offer enhanced corrosion resistance for demanding environments.

Frequently Asked Questions

1. What is a dual plate check valve?

A dual plate check valve uses two spring-loaded plates that open during forward flow and close automatically when flow reverses.

2. Why choose SS304 disc?

SS304 stainless steel offers better corrosion resistance than standard ferrous materials.

3. What is the advantage of wafer type design?

Wafer type valves are compact, lightweight, and easy to install between flanges.

4. What does PN16 mean?

PN16 indicates a nominal pressure rating of 16 bar.

5. How does it reduce water hammer?

The spring-assisted fast closing mechanism reduces reverse flow shock.

Request a Quote

For pricing, OEM supply, dealership enquiries, or bulk orders for PN16 Dual Plate Check Valve with SS304 Disc – Wafer Type, contact Poline Valves today.
